1GE EPON FTTH ONU with Route Mini Plastic White Housing

Brand:

Price:

Pieces

get latest price

< >

Color:

default

Size:

default

Shipping From:

China
Russia

Shipping:

Please select the country you want to ship from

Quantity:

- + Piece

Total Price:

Depends on the product properties you select

Buy Now Add to Cart Inquire Now

< >

Product Details
Supplier Detail

For more information, please feel free to contact me.

SkypeID: sophia.vss | WhatsApp ID: 008613802447798

Choose V-Solution, Choose Professional

Special Features
   ► Plug and play, features auto-detecting, auto-configuration, and auto firmware upgrade, etc.
   ► Integrated OAM remote configuration and maintenance function.
   ► Support rich QinQ VLAN functions and IGMP Snooping multicast features.
   ► Functions like transceiver diagnostic monitoring, transmitter disable, etc.
   ► Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset.

Technical parameters

Technical items	Description
Technical items	V2801ZE / NL2801ZE
main chip	ZTE ZX279110
Upstream PON interface	1 EPON interface, SC single-mode/single-fibre, symmetric 1.25 Gbps
Wavelength	Tx 1310nm, Rx 1490nm
Optical interface	SC connector
Downstream LAN interface	1 10/100/1000Mbps auto adaptive Ethernet interfaces, Full Duplex/Half Duplex, RJ45 connectors
Indicators	5 indicators, for status of power supply, PON port and 1 Giga-Ethernet port.
DC power supply	+12V, external AC-DC power adaptor
Power switch	1
Power consumption	≤3W
Operating condition	Operating temp: -5~+55℃ Operating humidity:10~90%(non-condensed)
Storing condition	Storing temp: -30~+60℃ Storing humidity:10~90%(non-condensed)
Dimension	120mm78mm28mm(lengthwidthheight)
Net weight	0.2Kg
