    2835 high brightness LED injection module with lens

    Price:
    Pieces
    get latest price

    < >
    Please select a Color
    Please select a Size
    Please select a Ships From
    Please select the country you want to ship from
    Please select the country you want to ship from
    - + Pieces
    This product can't be shipped to the selected region by express delivery.If you want to buy this product,you can click inquire now to contact seller
    Depends on the product properties you select
    Buy Now Add to Cart Inquire Now


    Parameters                          (Room temperature   =25℃)

    Items

    Parameter

    Unit

    LED type

    2835


    LED Quantity

    3

    PCS

    Concatenation

    20

    PCS

    Dimension

    68*14*7.2

    mm

    Power

    0.72±10％

    W

    Input V.

    DC12V

    V

    Input C.

    0.06

    A

    Surface Temp.

    < 40

    ℃

    Working Temp.

    -20 ～ +45

    ℃

    Storage Temp.

    -30 ～ +60

    ℃

    Protect Level

    IP65

    -

     Optical and Electrical Parameters               (Room   temperature =25℃)

    Test Item

    Test Condition

    Symbol

    Parameters

    Unit

    Min.

    Typical

    Max

    Color Temperature

    DC12V

    CCT

    15000

    18000

    22000

    K

    Ra

    DC12V

    CRI

    75

    80

    85

    --

    Luminous Flux

    DC12V

    Φ

    -

    60

    -

    lm

    Light Efficiency

    DC12V

    LPW

    70

    75

    82

    lm/W

    Visual Angle

    DC12V

    Wd

    --

    160

    --

    Deg


    Characteristics

    ● High brightness SMD 2835 LEDs with heat sink

    ● 160 degree beam angle

    ● Constant current driver

    ● Moisture-proof, water-proof,dust proof

      and impact resistance.

    ● Professional multi-optic design,best brightness,

      no bright dots.

    ● IP65 protection level.

    ● Nice structure and injection molding process.

    ● All raw material with RoHS standard

    ● Long lifespan and low failure rate
